ES SERIES PORTABLE CARPET SPOTTERS (230V)
MODEL 98221
CIRCUIT ASSEMBLY /PARTS LIST (ref. drawing 31078)
ITEM
NO.
DESCRIPTION PART
NO.
QTY.
*1
WASHER-LOCK (H/S) #10
01713 1
*2
SCREW-TCT (F) PAN HEAD #10-32 X 3/8"
03261 1
3
TERMINAL-CLOSED END CRIMP(INS)
06824 1
*4
STRAIN RELIEF(LIQ. TITE) .35 DIA. CORD
18793 1
*5
1/4" INSOLATED FEMALE CONNECTOR(S)
15139 9
*6
ASSEMBLY-POWER CORD, 115V (SPOTTER)
(INCLUDES ITEM 4)
19499 1
7
ASSEMBLY-POWER CORD, 230V (SPOTTER)
19500 1
8
LEAD-14 GA. X 3" BLACK ON POWER SWITCH
(INCLUDES ITEM 5 ON ONE END AND ITEM 11 ON THE
OTHER END)
19466 2
9
LEAD-16 GA. X 12" BLACK
(INCLUDES ITEM 5 ON EACH END)
19537 1
10
LEAD- 16 GA. X 12" WHITE
(INCLUDES ITEM 5 ON EACH END)
19538 1
*11
5/16" NON-INSOLATED PIGGY-BACK
FEMALE END CONNECTOR(S)
15391 2
12
LEAD- 14 GA. X 12" GREEN FROM MOTOR (INCLUDES
ITEM 5 ON ONE END AND ITEM 13 ON THE OTHER END)
80673 1
*13
3/16" NON-INSOLATED LOOP END CONNECTOR(S)
15200 1
14
BLACK LEAD WIRE FROM POWER CORD
(INCLUDES ITEM 5 ON THE END)
1
15
TERMINAL-Q.D.FEMALE 1/4"X 22/18GA. (FUL. INS)
19503 1
16
WHITE LEAD WIRE FROM POWER CORD
(ICONNECTED TO ITEM 3)
1
17
GREEN LEAD WIRE FROM POWER CORD
(INCLUDES ITEM 5 ON THE END)
1
18
LEAD- 16 GA. X 12" WHITE FROM PUMP
(INCLUDES ITEM 5 ON ONE END AND
AND IS CONNECTED TO ITEM 3 ON THE OTHER END)
19538 1
19
LEAD- 16 GA. X 12" BLACK FROM PUMP
(INCLUDES ITEM 5 ON EACH END)
19537 1
20
VACCUM MOTOR 230V/50-60HZ
17425 1
21
PUMP-55 PSI/230VAC
31480 1
22
FILTER
31067 1
*23
POWER CORD 230V
31059 1
24
POWER SWITCH
30472 1
