FuelPump(MachinewithYanmarDieselEngine)

g213682

Figure276

1.Pumpdischargehose

2.Fuel/waterseparator

3.Fuelpump

OnmachineswithaYanmardieselengine,thefuelpumpisattachedtotheair

cleanerstandadapterbelowthefuel/waterseparator(Figure276).Electrical

currentisavailableforthefuelpumpwhenthekeyswitchisineithertheRUN

orSTARTposition.

TheT oroElectronicController(TEC)energizesthefuelpump.

IMPORTANT

Whentestingthefuelpump,ensurethatthepumpisnotoperated

withoutfuel.

DANGER

Dieselfuelishighlyammable.

•Usecautionwheneveryouhandledieselfuel.

•Donotsmokewhiletestingthefuelpump.

•Donottestthefuelpumpwhiletheengineishot.

•Ensurethatthereisadequateventilationwhentesting.

•Alwayswipeupanyspilleddieselfuelbeforestartingtheengine.

TestingtheFuelPumpCapacity

1.Parkthemachineonalevelsurface,lowerthecuttingunits,shutoffthe

engine,andsettheparkingbrake.EnsurethatthekeyswitchisintheOFF

position.

2.Unlatchthehoodandraiseit.

3.Ensurethatthefuelhosesattachedtothefuelpumparefreeofobstructions.

ElectricalSystem:TestingtheElectricalComponents

Page7–108

Reelmaster

5410/5510/5610Series

15216SLRevC
