Greensmaster Flex 21
Page 6 – 10
Chassis and Controls
Wheels
Removal
1. Park mower on a level surface. Make sure the engine
is OFF.
2. Push kickstand down with one foot while pulling up
on the handle. This will support the mower on the kick-
stand.
3. Pivot wheel locking clip away from the center of the
wheel. Slide wheel off the wheel hex shaft.
Installation
1. Make sure mower is parked on a level surface and
the engine is OFF.
2. Push kickstand down with one foot while pulling up
on the handle. This will support the mower on the kick
stand.
3. Apply anti–seize lubricant to the exposed end of the
wheel hex shaft.
4. Slide wheel completely onto the wheel hex shaft until
the locking clip is secured into the groove on the wheel
hex shaft.
1. Wheel locking clip 2. Wheel hex shaft
Figure 14
1
2
1. Wheel hex shaft 2. Kickstand
Figure 15
1
2
Anti–seize lubricant
