Toro 04202 Installation Instructions

7
LubricatingandAdjusting
theMachine
NoPartsRequired
Procedure
1.Lubricatethemachineaccordingtothe
instructionsinyourOperator’sManual.
2.Fillthegearcasewithoilaccordingtothe
instructionsinyourOperator’sManual.
3.Filltheenginecrankcasewithoilaccordingto
theinstructionsinyourOperator’sManual.
4.Adjusttheenginespeedtothefollowing
specications:
Highidle(noload)
3300to3500rpm
Lowidle(noload)
1800to2000rpm
ProductOverview
g265059
Figure19
1.Chokelever
3.Recoilstarterhandle
2.Fuel-shutoffvalve
Controls
ChokeControl
Thechokecontrolislocatedonthesideoftheengine
(Figure19);youuseittohelpstartacoldengine
Note:Donotstartorrunawarmenginewiththe
chokeintheCLOSEDposition.
•Movethechokeleverallthewaytotheleft
(awayfromstarterhandle)tosetthechoketothe
CLOSEDposition.
•Movethechokeleverallthewaytotheright
(towardstarterhandle)tosetthechoketothe
OPENposition.
Fuel-ShutoffValve
Thefuel-shut-offvalveislocatedonthesideofthe
enginebelowthechokecontrol(Figure19).
Note:Closethefuel-shut-offvalvewhenthemachine
isnotusedforafewdays,duringtransporttoand
fromthejobsite,orwhenthemachineisparked
insideabuilding;refertoOpeningandClosingthe
Fuel-Shut-OffValve(page16).
14
