•Agreenlightindicatesthatthechargerisfully
chargedorthechargerisdisconnectedfromthe
battery.
•Aashinglightthatalternatesbetweenredand
greenindicatesthatthebatteryisnearlyfully
charged.Thisstatelastsonlyafewminutesuntil
thebatteryisfullycharged.
ReplacingtheFuse
Electric-StartModelOnly
Ifthebatterydoesnotchargeortheenginedoesnot
runwiththeelectricstarter,thefusemaybeblown.
Replaceitwitha40Aplug-intypefuse.
1.RefertoPreparingforMaintenance(page20).
2.Raisethereardeectorandlocatethebattery
compartment(Figure31).
Note:Thereisanadhesive-backedcovering
thatprotectsthebatterycompartment.
g009506
Figure31
1.Reardeector
3.Battery
2.Screw
4.Batterycompartment
3.Wipeawayanydebrisinthebatterycompartment
areaandremovetheadhesive-backedcovering.
4.Removethescrewthatsecuresthebattery
compartment,pulloutthebattery,andlocatethe
fuse(Figure31andFigure32).
g030022
Figure32
1.Batterycover3.Fuseholder
2.Fuse
5.Replacethefuseinthefuseholder(Figure32).
Note:Yourmachinecomeswithasparefuse
attachedtothebattery-chargerbox(Figure37).
g030053
Figure33
1.Batterycompartment2.Battery-chargerbox
6.Installthebatterycompartmentwiththescrew
thatyouremovedinstep4.
7.Installthecoveringoverthebattery
compartment.
8.Lowerthereardeector.
23
