260 Series Tractor Service Manual 1 - 3
SPECIFICATIONS
Hydrostatic Transaxles
Identification:
Tuff Torq Model K61A Transaxle
MVC-080X
General Specifications
Used 1994 – 1999
Lubrication SAE 10W-30 API Service Classification SH or higher. Alternate oil: A
synthetic oil (5w50 or similar viscosity range) may be used in place of SAE 10w30. This will
permit an increase in the maximum operating temperature of approximately 18°F (10°C).
Oil Capacity 3.5 qt. (3.3 liter)
Oil Level Check when transaxle is cold. Oil should be checked at the reservoir cup, located under the
front hood, on the panel support; oil level should be at the cold mark.
Fluid Change The transaxle is factory filled and does not require regular oil changes.
Ground Speed Forward 0-5.2 MPH (0-8.3km/h)
Reverse 0-2.3 MPH (0-3.7km/h)
