Toro 30150 - Height-Of-Cut Chart

24
Height-of-Cut Chart
No. of Spacers Below
Caster
Number of 1/4 inch Blade Spacers Below Spindle
Axle
Position
1/2 inch
(13mm)
3/16 inch
(5 mm)
4 3210
A 0 0
1 inch
(26 mm)
1–1/4 inch
(32 mm)
1–1/2 inch
(38 mm)
1–3/4 inch
(45 mm)
2 inch
(45 mm)
A 0 1
1–1/8 inch
(29 mm)
1–3/8 inch
(35 mm)
1–5/8 inch
(41 mm)
1–7/8 inch
(48 mm)
2–1/8 inch
(55 mm)
A 1 0
1–3/8 inch
(35 mm)
1–5/8 inch
(41 mm)
1–7/8 inch
(48 mm)
2–1/8 inch
(55 mm)
2–3/8 inch
(55 mm)
B 0 1
1–3/8 inch
(35 mm)
1–5/8 inch
(41 mm)
1–7/8 inch
(48 mm)
2–1/8 inch
(55 mm)
2–3/8 inch
(61 mm)
B 1 0
1–5/8 inch
(41 mm)
1–7/8 inch
(48 mm)
2–1/8 inch
(55 mm)
2–3/8 inch
(61 mm)
2–5/8 inch
(67 mm)
B 1 1
1–3/4 inch
(45 mm)
2 inch
(52 mm)
2–1/4 inch
(58 mm)
2–1/2 inch
(64 mm)
2–3/4 inch
(70 mm)
B 2 0
2 inch
(45 mm)
2–1/4 inch
(58 mm)
2–1/2 inch
(64 mm)
2–3/4 inch
(70 mm)
3 inch
(76 mm)
C 1 1
1–7/8 inch
(48 mm)
2–1/8 inch
(55 mm)
2–3/8 inch
(61 mm)
2–5/8 inch
(67 mm)
2–7/8 inch
(73 mm)
C 2 0
2–1/8 inch
(55 mm)
2–3/8 inch
(61 mm)
2–5/8 inch
(67 mm)
2–7/8 inch
(73 mm)
3–1/8 inch
(79 mm)
C 2 1
2–1/4 inch
(58 mm)
2–1/2 inch
(64 mm)
2–3/4 inch
(70 mm)
3 inch
(76 mm)
3–1/4 inch
(82 mm)
C 3 0
2–1/2 inch
(64 mm)
2–3/4 inch
(70 mm)
3 inch
(76 mm)
3–1/4 inch
(82 mm)
3–1/2 inch
(89 mm)
D 2 1
2–3/8 inch
(61 mm)
2–5/8 inch
(67 mm)
2–7/8 inch
(73 mm)
3–1/8 inch
(79 mm)
3–3/8 inch
(86 mm)
D 3 0
2–1/2 inch
(64 mm)
2–3/4 inch
(70 mm)
3 inch
(76 mm)
3–1/4 inch
(82 mm)
3–1/2 inch
(89 mm)
D 3 1
2–3/4 inch
(70 mm)
3 inch
(76 mm)
3–1/4 inch
(82 mm)
3–1/2 inch
(89 mm)
3–3/4 inch
(96 mm)
D 4 0
3 inch
(76 mm)
3–1/4 inch
(82 mm)
3–1/2 inch
(89 mm)
3–3/4 inch
(96 mm)
4 inch
(102 mm)
E 3 1
2–7/8 inch
(73 mm)
3–1/8 inch
(79 mm)
3–3/8 inch
(86 mm)
3–5/8 inch
(92 mm)
3–7/8 inch
(99 mm)
E 4 0
3–1/8 inch
(79 mm)
3–3/8 inch
(86 mm)
3–5/8 inch
(92 mm)
3–7/8 inch
(99 mm)
4–1/8 inch
(105 mm)
E 4 1
3–1/4 inch
(82 mm)
3–1/2 inch
(89 mm)
3–3/4 inch
(96 mm)
4 inch
(102 mm)
4–1/4 inch
(108 mm)
