Models 38409 & 38414
1. Eyebolt
2. Control cable
3. Spring cover
4. Control bar bracket
5. Top hole
6. Bottom hole
1
2
3
1/16–1/8”
m–2709
4
Models 38422 & 38424
1. Eyebolt
2. Control bar bracket
3. Rear hole
4. Forward hole
111
1
2
3
1. Add oil to small amount of
gasoline
2. Install cap and shake can
to mix
3. Add remaining amount of
gasoline
1
2
3
5
4
6
642
1. Key switch
2. Primer
3. Recoil start
4. Choke
5. Elec. start button*
6. Cord connection*
* ELEC. START MODEL
