Models 38409 & 38414
1. Chute handle
2. Chute deflector handle
3. Deflector mounting nuts
2
3
1
629
Models 38422 & 38424
1. Chute crank
2. Chute deflector handle
3. Deflector mounting nuts
1
2
630
3
Models 38422 & 38424
1. Spring cover
2. Cable adjuster
3. Z fitting
634
1/16”
1
1. Scraper
12
13
14
15
