2.InstallingtheDischarge
Chute
1Dischargechute
1
Chutehandle
3Phillipsheadscrews
3Washers
3Locknuts
Procedure
Installthedischargechuteasshown(Figure6).
Figure6
ProductOverview
Figure7
1.Dischargechute6.Knobs
2.Chutehandle7.Handlebolt(2)
3.Controlbar
8.Rotorblades
4.Handle9.Fueltankcap
5.Controlpanel
Figure8
1.Keyswitch3.Recoilstart
2.Primer
4.Chokelever
