AdjustingtheHandleHeight
Youmayraiseorlowerthehandletoapositionthatiscomfortableforyou.RefertoFigure11forthisprocedure.
1.Rotatethehandlelocks.
2.Loosenthenutssothatthecarriageboltcanslideintothehigherorlowerposition.
3.Movethehandletothehigherorlowerposition.
4.Tightenthenuts.
5.Lockthehandlesintoposition
g392241
Figure11
1.Boltandhandleinstalledtothehigherhandleposition.2.Boltandhandleinstalledtothelowerhandleposition.
