The battery must be removed from the machine so it
can be filled with electrolyte and charged. Bulk elecĆ
trolyte with 1.260 specific gravity must be purchased
from a local battery supply outlet. Remove the batĆ
tery and activate it as follows:
Tip seat forward exposing battery.
Remove wing nut securing battery hold downs to
rider chassis (Fig. 4).
-+74)
Lift up on top battery hold down and pivot rearĆ
ward.
Remove battery from chassis and set it aside.
Remove filler caps from battery and slowly fill
each cell until electrolyte is just above the LOWER"
fill line.
Leave filler caps off and connect a 3Ć4 amp batĆ
tery charger to battery posts. Charge battery at a
rate of 4 amperes or less for 4 hours (12 volt).
When battery is charged, disconnect charger
from electrical outlet and battery posts.
Slowly add electrolyte or distilled water to each
cell until level is just below the UPPER" fill line. ReinĆ
stall filler caps. Once battery is in service, distilled
water only should be added; never add more elecĆ
trolyte.
2 126 28)4*-// &%66)4: /)'642/:6)
9-// 28)4*/29 2162 26,)4 3%465 %1( 5)8)4) '2442;
5-21 %1( ()6)4-24%6-21 9-// 4)57/6
Install the battery with the terminal posts toward
the rear of the machine and vent tube on left side of
battery, thru hole in frame (Fig. 5).
1
2
-+74)
Reinstall battery hold downs.
#
) 574) &%66)4: ,2/( (2915 (2 126 627',
&%66)4: 32565 (74-1+ 4)-156%//%6-21 2* &%66)4:
216%'6 &)69))1 &%66)4: ,2/( (2915 %1(
32565 '27/( 4)57/6 -1 3)4521%/ -1.74: %1(24
(%0%+) 62 6,) )/)'64-'%/ 5:56)0
Install the red positive cable (rubber boot over
end) to the positive (+) terminal and the negative
cable (black) to the negative (ć) terminal of the batĆ
tery and secure with capscrews and wing nuts. Slide
the rubber boot over the positive terminal to prevent
a possible shortĆout from occurring (Fig. 5).
#
The rider is shipped from the factory without oil in
the crankcase.
Place rider on a level surface.
Unscrew and remove the dipstick from the oil fill
tube (Fig. 6).
Insert a funnel into the tube and slowly add enĆ
gine oil into the crankcase, using oil fill chart below.
Use a high quality detergent oil classified For SerĆ
vice SG". Oil viscosity (weight) must be selected acĆ
cording to anticipated ambient temperature.
-/ -// ,%46
1132 Rear Engine Rider 48 ounces of oil
