Toro 74314 Setup Instructions

g036545
Figure15
1.Bolts2.Rubberguard
4.Foldtheguardforward.
5.Installthemetalguardswiththeattachedbolts
showninFigure16.
g035552
Figure16
1.Guardattachedtothe
mowerdeck
3.Metalguards
2.Bolts
6.Installtherubberguardwiththebolts(Figure
15).
5
CheckingtheTirePressure
NoPartsRequired
Procedure
Pressure:103kPa(15psi)
Note:Checkthetirepressurebeforestartingthe
machine.RefertoyourOperator’sManualforthe
correcttiretype,correctairpressureneeded,and
procedure.
6
CheckingtheEngine-Oil
Level
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,
checktheoillevelintheenginecrankcase;refer
toServicingtheEngine-OilLevelintheOperator's
Manual.
7
CheckingtheTorqueofthe
WheelLugNuts
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,
checkthewheellugnuttorque;refertoCheckingthe
WheelLugNutsintheOperator'sManual
8

Toro 74314 Specifications

General

Model	74314
Deck Material	Steel
Cutting Width	22 inches
Drive Type	Self-propelled
Drive System	Personal Pace
Oil Capacity	20 oz
