ProductOverview
Figure4
1.Engine
5.KeyChoice
®
control
9.Anti-scalproller13.Reardrivewheel
2.Seat
6.Mowerdeck
10.Deector14.Controlpanel
3.Gas-tankcap
7.Frontcasterwheel
11.Height-of-cutlever
4.Steeringwheel
8.Traction-controlpedal
12.SmartPark
™
switch
Controls
BecomefamiliarwithallcontrolsinFigure5andFigure6
beforeyoustarttheengineandoperatethemachine.
Figure5
ControlPanel
1.SmartPark™switch
5.Blade-controlswitch
(powertakeoff)
2.Throttle
6.Parkingbrake—On
3.Choke
7.Parking-brakeindicator
light
4.Ignitionswitch
8.Parkingbrake—Off
Figure6
1.Operating-in-reverse
warninglight
3.Fuel-presencewindow
2.KeyChoicekey(bluein
color)
IgnitionSwitch
Theignitionswitchhas3positions—OFF,RUNandSTART.
ThekeyturnstotheSTARTpositionandmovesbackto
theRUNpositionuponrelease.TurningthekeytotheOFF
positionstopstheengine.Alwaysremovethekeywhen
leavingthemachinetopreventsomeonefromaccidentally
startingtheengine(Figure5).
ChokeControl
Usethechoketostartacoldengine.Pullthechokeknob
uptoengageit.Pushdownthechokeknobtodisengage
it(Figure5).
15
