ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance;however,ifafuseblows,checkthe
component/circuitforamalfunctionorshort.
Fusetype:
•Main—F1(15A,blade-type)
•ChargeCircuit—F2(25A,blade-type)
ToreplacetheMain(15A)fuse,reachintothe
openinginthesideoftheconsole,pulloutthefuse,
andinstallanew15Afuse(Figure46).
g297599
Figure46
1.Main(15A)2.Consoleopening
ToreplacetheChargeCircuit(25A)fuse,locatethe
fusetotheleftofbattery,pulloutthefuse,andinstall
anew25Afuse(Figure47).
g297598
Figure47
1.Chargecircuit(25A)
DriveSystem
Maintenance
CheckingtheTirePressure
ServiceInterval:Every25hours—Checktire
pressure.
Maintaintheairpressureinthefrontandreartiresas
specied.Uneventirepressurecancauseuneven
cut.Checkthepressureatthevalvestem(Figure48).
Checkthetireswhentheyarecoldtogetthemost
accuratepressurereading.
Inatethefrontcasterwheeltiresto103kPa(15psi).
Inatethereardrivewheeltiresto90kPa(13psi).
g000554
Figure48
1.Valvestem
