FormNo.3442-155RevA
Titan
®
MR4800orMR5400
RidingMower
ModelNo.75314—SerialNo.400000000andUp
ModelNo.75315—SerialNo.400000000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)
*3442-155*

Table of Contents

Other manuals for Toro 75314

Questions and Answers

  • M
    Michelle WatsonAug 12, 2025
    Why Toro 75314 Lawn Mower engine does not start, starts hard, or fails to keep running?
    • M
      michael38Aug 12, 2025
      Several factors can cause this issue: * The fuel tank might be empty, so fill the fuel tank. * The choke (if applicable) might not be on, so move the choke lever to the ON position. * The air cleaner could be dirty, so clean or replace the air-cleaner element. * The spark-plug wire(s) might be loose or disconnected, so install the wire(s) on the spark plug. * The spark plug(s) might be pitted, fouled, or the gap is incorrect, so install a new, correctly gapped spark plug(s). * There might be dirt in the fuel filter, so replace the fuel filter. * There might be incorrect fuel in the fuel tank, so drain the tank and replace the fuel with the proper type. * The oil level in the crankcase might be low, so add oil to the crankcase.
  • W
    William MendozaAug 16, 2025
    Why Toro 75314 engine loses power?
    • P
      paularodriguezAug 16, 2025
      Your Toro Lawn Mower engine might be losing power due to several reasons: * The engine load is excessive; reduce the ground speed. * The air cleaner is dirty; clean the air-cleaner element. * The oil level in the crankcase is low; add oil to the crankcase. * The cooling fins and air passages under the engine blower housing are plugged; remove the obstruction from the cooling fins and air passages. * The spark plug(s) is pitted, fouled, or the gap is incorrect; install a new, correctly gapped spark plug(s). * There is dirt in the fuel filter; replace the fuel filter.
  • R
    Richard LongAug 20, 2025
    How to fix uneven cutting height on Toro 75314 Lawn Mower?
    • A
      Austin RobersonAug 20, 2025
      To address an uneven cutting height on your Toro Lawn Mower: * Sharpen the blade(s) if they are not sharp. * Install a new cutting blade(s) if a cutting blade(s) is/are bent. * Level the mower from side-to-side and front-to-rear if the mower is not level. * Adjust the anti-scalp wheel height if an anti-scalp roller (if applicable) is not set correctly. * Clean the underside of the mower deck if it is dirty. * Adjust the tire pressure if it is incorrect.
  • P
    peter89Aug 23, 2025
    What to do if Toro 75314 blades do not rotate?
    • T
      Timothy JohnsonAug 25, 2025
      If the blades on your Toro Lawn Mower do not rotate: * Install a new drive belt if the drive belt is worn, loose or broken. * Install the drive belt and check the adjusting shafts and belt guides for the correct position if the drive belt is off of the pulley. * Install a new mower belt if the mower belt is worn, loose, or broken.
  • W
    weaverbrianAug 27, 2025
    What to do if my Toro 75314 engine overheats?
    • A
      andrew62Aug 27, 2025
      If your Toro Lawn Mower engine overheats, consider the following: 1. The engine load might be excessive, so reduce the ground speed. 2. The oil level in the crankcase might be low, so add oil to the crankcase. 3. The cooling fins and air passages under the engine-blower housing might be plugged, so remove the obstruction from the cooling fins and air passages. 4. The air cleaner might be dirty, so clean or replace the air-cleaner element.
  • M
    mark92Aug 31, 2025
    What to do if my Toro Lawn Mower starter does not crank?
    • M
      Michelle WatsonAug 31, 2025
      If the starter on your Toro Lawn Mower doesn't crank, check these items: * The blade-control switch may be engaged; disengage the blade-control switch. * The motion-control levers may not be in the NEUTRAL-LOCK position; move the motion-control levers outward to the NEUTRAL-LOCK position. * The battery may be dead; charge the battery. * The electrical connections may be corroded or loose; check the electrical connections for good contact. * A fuse may be blown; replace the fuse.
  • S
    Sean RussoSep 4, 2025
    Why does my Toro 75314 Lawn Mower vibrate abnormally?
    • J
      Joshua MillsSep 4, 2025
      Abnormal vibrations in your Toro Lawn Mower can be caused by: * Bent or unbalanced cutting blade(s): Install new cutting blade(s). * Loose blade mounting bolt: Tighten the blade mounting bolt. * Loose engine mounting bolts: Tighten the engine mounting bolts. * Loose engine pulley, idler pulley, or blade pulley: Tighten the appropriate pulley.
  • L
    Lisa LandrySep 7, 2025
    Why Toro 75314 Lawn Mower fuel tank is collapsing?
    • R
      Ronald JacksonSep 7, 2025
      If the fuel tank is collapsing or the machine frequently shows signs of running out of fuel, it could be because the air-cleaner paper element is clogged. Clean the paper element.

Summary

Safety

General Safety

Core safety guidelines for operating the machine to prevent injury or death.

Slope Indicator

Controls

Operation

Before Operation Safety

Pre-operation checks and safety precautions to prevent injury.

During Operation Safety

Safety practices and warnings for operating the machine.

Slope Safety

Detailed safety instructions for operating the machine on slopes.

Starting the Engine

Step-by-step procedure for safely starting the engine.

After Operation

Maintenance

Maintenance Safety

Essential safety precautions before performing any maintenance.

Recommended Maintenance Schedule(s)

A schedule of required maintenance tasks and intervals.

Engine Maintenance

Procedures for servicing the engine, including air cleaner and oil.

Storage

Troubleshooting

Toro 75314 Specifications

General IconGeneral
BrandToro
Model75314
CategoryLawn Mower
Deck MaterialSteel
Drive TypeSelf-Propelled
StarterRecoil
TypeWalk Behind Mower
Drive SystemRear-Wheel Drive
Fuel Capacity1.0 US qt (0.95 l)
Fuel Tank Capacity1.0 US qt (0.95 l)
