Figure72
1.Liftarm
3.Washer
2.Hairpincotter
7.Removetheliftarmfromthedeckpin(Figure
72).
8.Repeatsteps6and7fortheothersideofthe
machine.
9.Slidethemowerdeckrearwardtoremovethe
mowerbeltfromtheenginepulley.
10.Slidethemowerdeckoutfromunderneaththe
machine.
Note:Retainallpartsforfutureinstallation.
InstallingtheMowerDeck
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Slidethemowerunderthemachine.
4.Lowertheheight-of-cutlevertothelowest
position.
5.On1sideofthemachine,lifttherearofthe
mowerdeckandinstalltheliftarmtothedeck
pin(Figure72).
6.Installtheliftarmusingthewasherandhairpin
cotter(Figure72).
7.Repeatsteps5and6fortheothersideofthe
machine.
8.Attachthefrontsupportrodtothemowerdeck
withtheclevispinandhairpincotter(Figure71).
9.Installthemowerbeltontotheenginepulley;
refertoReplacingtheMowerBelt(page40).
ReplacingtheGrass
Deector
ServiceInterval:Beforeeachuseordaily—Inspect
thegrassdeectorfordamage.
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectstowardyouor
bystanders,resultinginseriousinjury.Also,
contactwiththebladecouldoccur.
Neveroperatethemachinewithoutthe
grassdeector,thedischargecover,orthe
grass-collectionsysteminplace.
1.Removethenut(3/8inch)fromtherodunder
themower(Figure73).
g296957
Figure73
1.Mowerdeck5.Rod
2.Shortstandoff6.Spring
3.Grass-deectorbracket
7.Nut(3/8inch)
4.Grassdeector
2.Slidetherodoutoftheshortstand-off,spring,
andgrassdeector(Figure73).
3.Removethedamagedorworngrassdeector.
4.Installthenewgrassdeector(Figure73).
5.Slidethestraightendoftherodthroughtherear
grassdeectorbracket.
6.Placethespringontherod,withendwires
down,andbetweenthegrassdeectorbrackets.
48
