A. SETTING THE TIME AND DATE
TURN THE DIAL TO SET TIME/DATE
• HOURS SHOULD FLASH
• ADJUST HOUR WITH THE +/- BUTTONS
• PRESS THE NEXT BUTTON
• MINUTES SHOULD FLASH
• ADJUST MINUTES WITH THE +/- BUTTONS
• PRESS THE NEXT BUTTON
• DAYS SHOULD FLASH
• ADJUST DAYS WITH THE +/- BUTTONS
• PRESS THE NEXT BUTTON
TURN DIAL TO AUTO/ON
B. SETTING THE PROGRAM START TIMES
TURN THE DIAL TO PROGRAM START TIME
• START TIME #1 SHOULD FLASH
• PRESS THE NEXT BUTTON
• HOURS SHOULD FLASH
• ADJUST HOUR WITH THE +/- BUTTONS
• PRESS THE NEXT BUTTON
• MINUTES SHOULD FLASH
• ADJUST MINUTES WITH THE +/- BUTTONS
• PRESS THE NEXT BUTTON
*START TIME #2 WILL FLASH. IF AN ADDITIONAL START TIME IS
NEEDED, REPEAT THE STEPS ABOVE.
C. SETTING THE VALVE RUN TIMES
TURN THE DIAL TO VALVE RUN TIME
• VALVE #1 SHOULD FLASH
• PRESS THE NEXT BUTTON
• RUN TIMES SHOULD FLASH
• ADJUST MINUTES WITH THE +/- BUTTONS
• PRESS THE NEXT BUTTON
*VALVE #2 SHOULD FLASH. REPEAT THE STEPS ABOVE FOR EACH
ADDITIONAL VALVE TO BE PROGRAMMED.
