Operation
ChargingtheBatteryPack
Important:Thebatterypackisnotfullycharged
whenyoupurchaseit.Beforeusingthetoolfor
thersttime,placethebatterypackinthecharger
andchargeituntiltheLEDdisplayindicatesthe
batterypackisfullycharged.Readallsafety
precautions.
Important:Chargethebatterypackonlyin
temperaturesthatarewithintheappropriate
range;refertoSpecications(page6).
Note:Atanytime,pressthebattery-charge-indicator
buttononthebatterypacktodisplaythecurrent
charge(LEDindicators).
1.Makesurethattheventsonthebatteryareclear
ofanydustanddebris.
2.Lineupthecavityinthebatterypack(Figure2)
withthetongueonthecharger.
g282651
Figure2
1.Batterypackcavity4.Handle
2.Batterypackventingareas
5.LEDindicators(current
charge)
3.Batterypackterminals6.Battery-charge-indicator
button
3.Makesurethattheventsonthebatterycharger
areclearofanydustanddebris.
4.Slidethebatterypackintothechargeruntilitis
fullyseated(Figure3).
g268087
Figure3
1.LEDindicatorlight
2.Chargerventingareas
5.Toremovethebatterypack,slidethebattery
backwardoutofthecharger.
6.RefertothefollowingtabletointerprettheLED
indicatorlightonthebatterycharger.
IndicatorlightIndicates
Off
Nobatterypackinserted
Greenblinking
Batterypackischarging
Green
Batterypackischarged
Red
Batterypackand/orbattery
chargerisoverorunderthe
appropriatetemperaturerange
Redblinking
Batterypackchargingfault*
*RefertoTroubleshooting(page9)formore
information.
