Toro Greensmaster Flex 2120 - Installing the Transport Wheels; Checking the Engine-Oil Level

4
InstallingtheTransport
Wheels
Optional
Partsneededforthisprocedure:
2
Transportwheels—TransportWheelKit(ModelNo.
04123[Optional])
Procedure
1.Useyourfoottopushthecenterofthekickstand
downandpulluponthelowerhandlesupport
untilthekickstandhasrotatedforwardandover
center(Figure9).
g016833
Figure9
1.Kickstand
2.Pressthewheellockingcliptowardthecenter
ofwheelandslidethewheelontothehexshaft
(Figure10).
g017591
Figure10
1.Lockingclip
3.Rotatethewheelbackandforthuntilittsonto
theaxleandthelockingclipissecuredinthe
grooveontheaxleshaft.
4.Repeattheprocedureontheoppositesideof
themachine.
5.Inatethetiresto83to103kPa(12to15psi).
6.Carefullylowerthemachineoffofthekickstand
bypushingforwardslowlyorbyliftingthelower
handlesupport,allowingthekickstandtospring
backtotheSTORAGEposition.
5
CheckingtheEngine-Oil
Level
NoPartsRequired
Procedure
Checktheengine-oillevel;refertoCheckingthe
Engine-OilLevel(page30).
10
