InstallingtheDischargeChute
Partsneededforthisprocedure:
1Dischargechute
1
Chutehandle
3Phillipsheadbolts
3Washers
3Locknuts
Procedure
Installthedischargechuteasshown(Figure7).
Figure7
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmachinedoesnotcomewithoilintheengine,butit
doescomewithabottleofoil.
Important:Beforestartingtheengine,lltheengine
withoil.
Note:Thebottleofoilmaycontainanounceortwomore
thantheenginerequires.Donotoverllorunderllthe
engine.
Maxll:20oz.(0.6l),type:automotivedetergentoilwithan
APIserviceclassicationofSJ,SL,orhigher.
Use
Figure8belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:
Figure8
1.Movethemachinetoalevelsurface.
2.Cleanaroundtheoilllcap(
Figure9).
Figure9
1.Oilllcap
