Toro ProLine H800 Setup Instructions

2
InstallingtheHopperDoor
Partsneededforthisprocedure:
6Flatwasher
2Bolt
2Locknut
Procedure
1.Removethehardwarefromthebracketsonthe
hopper.
2.Installthehopperdoortothehopperwiththe
previouslyremovedhardware;refertoFigure2.
g315991
Figure2
1.Hopperdoor3.Washer
2.Bolt4.Locknut
3
InstallingtheLatch
Partsneededforthisprocedure:
1Hook
1
Spacer
2Longbolt
1
Shortbolt
3Flatwasher
1Rodconnector
1
Spring
2Bushing
3Flangenut
2Locknut
Procedure
1.Installthehookandspacertothehopperwith
alongbolt,atwasher,angenut,spring,and
locknut(Figure3).
