5
Safety
and Instruction Decals
Safety
decals and instructions are easily visible to the operator and are located near any
area of potential danger
. Replace any decal that is damaged or lost.
ON
MOWER HOUSING
(Part No. 43–8480)
ON MOWER HOUSING
(Part No. 93–0248)
ON REAR HEIGHT ADJUSTER
(Part No. 92–2914 Right)
(Part No. 92–2915 Left)
ON MOWER HOUSING
(Part No. 99–6018)
Assembly
IMPORTANT:
Be extr
emely car
eful when unpacking
and handling the mower and upper handle so that you
do not pull, crimp, or in any way damage the cables.
Unpacking
the Mower
1. Open
the box from the top.
2.
Remove the lower handle from the box (models
20023, 20025, 20027, and 20061 only).
3.
Remove the fillers from the box, allowing the upper
handle to rest on the top of the mower
.
4.
Remove the mower from the box.
5.
Lay the upper handle on the ground behind the mower
with the handle label facing up and the control cables
routed between the handle mounting brackets (Fig. 1).
Assembling
the Handle
Models 20023, 20025, 20027, and 20061
1. Squeeze
the lower handle section ends together
,
position the holes in the handles over the pins on the
handle brackets, and release the handle (Fig. 1).
IMPORTANT
: The cables must be r
outed inside of the
lower handle and the starter r
ope outside the handle.
m–4215
1
3
4
4
2
Figure
1
1. Cable
2. Starter
rope
3.
Lower handle section
4. Pins
All Models
1. Remove
the four handle bolts and knobs that are
installed in the lower handle (two bolts will have flat
caps and two will be contoured to fit the handle).
2.
Swing the lower handle back and the support brackets
up, aligning the brackets with the holes in the handle
(Fig. 2).
3.
Secure the handle to the support brackets with the two
flat handle bolts and two knobs, using the height
adjustment holes on the brackets that best suit your
height requirements (Fig. 2)
m–4208
2
1
4
3
Figure
2
1. Lower
handle
2.
Support bracket
3. Knob
4.
Flat handle bolt
