ReplacingtheAirCleaner
ServiceInterval:Yearly
1.Pressdownonthelatchtabsontopoftheaircleaner
cover(Figure31).
Figure31
1.Latchtabs
3.Foampre-lter
2.Paperairlter
2.Openthecover.
3.Removethepaperairlterandthefoampre-lter
(Figure31).
4.Inspectthefoampre-lter,andreplaceitifitis
damagedorexcessivelydirty.
5.Inspectthepaperairlter.
A.Ifthepaperairlterisdamagedoriswetwithoil
orfuel,replaceit.
B.Ifthepaperairlterisdirty,tapitonahard
surfaceseveraltimesorblowcompressedairless
than30psi(207kPa)throughthesideofthelter
thatfacestheengine.
Note:Donotbrushthedirtoffthelter;
brushingforcesdirtintothebers.
6.Removedirtfromtheaircleanerbodyandcoverusing
amoistrag(totrapthedirtandkeepitfromfallinginto
theengine).Donotwipedirtintotheairduct.
7.Insertthefoampre-lterandthepaperairlterinto
theaircleaner.
8.Installthecover.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
Yearly
Runtheengineafewminutesbeforechangingtheoiltowarm
it.Warmoilowsbetterandcarriesmorecontaminants.
1.Performthepre-maintenanceprocedures;referto
PreparingforMaintenance(page17).
2.Removethedipstick.
3.Tipthemachineontoitsside,withthedipstickdown,
todraintheusedoiloutthroughtheoil-lltube(Figure
32).
G017475
Figure32
4.Afterdrainingtheusedoil,returnthemachinetothe
normaloperatingposition.
5.Removethedipstickandpourabout3/4ofthe
crankcasecapacityofoilintotheoil-lltube.
Note:Max.ll:20oz.(0.59l),type:SAE30orSAE
10W-30detergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.
6.Wipeoffthedipstickendwithacleancloth.
7.Insertthedipstickintotheoil-lltube,butdonot
screwitin.
8.Removethedipstickandreadtheoillevelonthe
dipstick(Figure33).
