Toro SMRT Logic - SMRT Logic Troubleshooting; LED Behavior and Solutions

13
LED Behavior Cause Solution
steady orange
SMRT Logic unable to
get an IP address from
the network’s DHCP
server.
Conrm the network is congured to assign IP addresses. If
needed, a SMRT Logic can be manually congured to use
a static IP address. Refer to Advanced SMRT Logic network
setup on the website.
blinks green
SMRT Logic unable to
reach the internet.
Conrm there is a valid internet connection using the same
Ethernet wire if possible.
SMRT Logic Troubleshooting
How It Works
SMRT Logic Specications
Model Name: SMRT Logic
Model Number: SMRT-T, SMRT-I, A-SMRT-T
Dimensions: 4.4” x 3.1” x 1.2” without antenna
Unit Weight: 3.4oz (95g) without accessories
Certication: FCC, IC, UL-Listed Power Adapter
Power: 5V DC, 1A
Port Speed: 10/100 Mbps
Operating Temp: 32 to 104°F (0-40°C)
Storage Temp: -4 to 140°F(-20 to 60°C)
Operating Humidity: 10 to 80% RH, non-condensing
