Toro Snow Blower 38515 - Loose Parts; Unfolding the Handle

105-1980
Reorderpartno.105-3521
Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1.
Nopartsrequired
–
Unfoldthehandle.
Dischargechute1
Chutehandle
1
Phillipsheadscrews3
Washers3
2.
Locknuts3
Installthedischargechute.
1.UnfoldingtheHandle
Procedure
1.Cuttheplastictiethatsecuresthecontrolcableto
thehandle.
Note:Holdthecabletauttoensurethatitstays
connectedatthebottom.
2.Loosentheknobs,pulloutthehandlebolts,and
rotatetheupperhandletotheoperatingposition
(Figure3).
G009177
Figure3
5
