Toro SnowMaster 824 QXE - Installing the Discharge Chute

2
InstallingtheDischargeChute
Partsneededforthisprocedure:
1
Bolt(1/4–20X1–1/2inches)
1
Locknut(1/4–20inch)
3
Carriagebolt(1/4–20x1inch)
3
Locknut(1/4–20inch)
1
Screw(1/4–20X5/8inch)
Procedure
1.Insertthechutepostthroughthebracketintothebase
ofthemachineandsecureitusingaboltandalocknut
(Figure5).
Figure5
1.Chutepost3.Locknut(1/4–20inch)
2.Bolt(1/4–20X1–1/2
inches)
4.Bracket
2.Assemblethechuterodandsecurethecables(Figure
6).
Figure6
6
