Toro Super Recycler 20382 - Bagging Grass Clippings; Installing the Grass Bag

BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
Note:Ensurethebagisseatedinthecorrectposition.
WARNING
Aworngrassbagcouldallowsmallstonesand
othersimilardebristobethrowntowardyouor
bystanders,resultinginseriouspersonalinjuryor
death.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
Iftheside-dischargechuteisonthemachine,removeit
andlocktheside-dischargedoor;refertoRemovingthe
Side-DischargeChute(page14)beforebaggingtheclippings.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheGrassBag
1.Routethestarterropearoundthelower-ropeguide
(Figure21).
G017483
Figure21
1.Lower-ropeguide
Note:Thelower-ropeguidereleasesthestarterrope
whenyoupulltherecoil-starthandle.
2.Raiseandholdupthedischargedeector(Figure22).
G017464
Figure22
1.Dischargedeector
2.Rear-dischargeplug
3.Pullouttherear-dischargeplug(Figure22).
4.Hangtheupperfrontedgeofthebagonthenotches
(Figure23).
G017484
Figure23
1.Dischargedeector2.Grassbag
Note:Ensurethatthegrassbagissecurelyinstalled
ontothemachine.
5.Lowerthedischargedeector.
