Installing the Rear Hitch
Parts Required
1 Rear hitch bracket
Remove the fasteners from the rear frame and use them to install the rear hitch bracket as
shown.
Figure 1 Before assembly
G454863
Bolts
Locknuts
Figure 2 After assembly
G454865
3464-689C Page 3
