Toro Z Master Series - Procedure 15: Installing ROPS Hardware (LPG Models); Procedure 16: Installing ROPS (International Gasoline Models); Procedure 17: Installing ROPS (Diesel Models)

15
InstallingtheROPSHardware
(LPGMachinesOnly)
Partsneededforthisprocedure:
1
Bolt(1/2x3-1/4inch)
1
Locknut(1/2inch)
Procedure
Installthebolt(1/2x3-1/4inch)andlocknut(1/2inch)
intotheopenholeintheRoll-OverProtectionSystem
(ROPS)—Figure25.Thiswillpreventtherollbarfrom
hittingthecylinderwhenloweredtothedownposition.
G013506
1
2 3
Figure25
1.Locknut(1/2inch)3.Bolt(1/2x3-1/4inch)
2.ROPS
16
InstallingtheROPS
(InternationalMachines
UsingGasolineOnly)
Partsneededforthisprocedure:
1
Roll-OverProtectionSystem(ROPS)Kit
Procedure
InstalltheRoll-OverProtectionSystem(ROPS)Kit.Follow
theinstructionsincludedwiththeROPSKit.
17
InstallingtheROPS(Diesel
MachinesOnly)
Partsneededforthisprocedure:
1Rollbar,rightsection
1
Rollbar,leftsection
1Rollbar,centersection
8
Bolt(3/8x1inch)
8
Curvedwasher
8
Flangenut(3/8inch)
2
Bolt(1/2x3–1/4inch)
2
Flangenut(1/2inch)
Procedure
1.Looselyinstalltherightandleftrollbarsectiontothe
frame,with8bolts(3/8x1inch),8curvedwashers,
and8angenuts(3/8inch).
Note:Installthecurvedwasherconetowardthebolt
head.
11
