Toro Z Master Series - Procedure 1: Removing Machine from Crate

ProcedureDescription
Qty.
Use
Bolt(1/2x3-1/4inch)
1
15
Locknut(1/2inch)
1
InstalltheROPShardware(LPG
machinesonly).
16
Roll-OverProtectionSystem(ROPS)Kit
1
InstalltheROPS(International
machinesusinggasolineonly).
Rollbar,rightsection1
Rollbar,leftsection
1
Rollbar,centersection1
Bolt(3/8x1inch)
8
Curvedwasher
8
Flangenut(3/8inch)
8
Bolt(1/2x3–1/4inch)
2
17
Flangenut(1/2inch)
2
InstalltheROPS(Dieselmachines
only).
18
Number2general-purposelithium-base
ormolybdenum-basegrease.(Purchase
separately.)
1tube
Checkthemachineforgrease.
19
Nopartsrequired
–
Removetheshippingstraps.
20
Nopartsrequired
–
Checkthemachinebeforedeliveryto
thecustomer(Allmachines).
Operator'sManual
1
EngineOwner'sManual
1
Registrationcard1
Operator-trainingmaterial
1
21
Key2
Deliveringthemachinetothecustomer
(Allmachines).
1
RemovingtheMachinefroma
Crate
Partsneededforthisprocedure:
2
Rearwheels(Woodencrateonly)
RemovingaMachinefromaMetalCrate
Ifremovingthemachinefromametalcrate,refertothe
Dealer/DistributorPortalforfurtherinformation.
RemovingtheMachinefromaWooden
Crate
1.Removethescrewsholdingtherightangleretaining
platetothecrate.
Figure1
GasolineMachineShown
Figure2
DieselMachineShown
2
