2.Raisethebackofthemachineupandsupportitwith
jack-stands.
Figure3
GasolineMachineShown
Figure4
DieselMachineShown
3.Removethewheelnutsfrombothsidesofthevehicle
andremovetherightangleretainingplate.Discardthe
screwsandretainingplate.
Figure5
DieselMachineShown
4.Mountthewheelswiththevalvestemtotheoutside
andsecurethemwiththewheelnutspreviously
removed.
5.Torquethewheelnutsto95ft-lb(128N-m).
6.Removethejackstands.
Figure6
GasolineMachineShown
Figure7
DieselMachineShown
2
AddingFueltotheMachine
NoPartsRequired
AddingFueltoMachines
Addfueltothemachinebeforestartingit.Refertoyour
Operator’sManualforthecorrectfuelandprocedure.
AddingFueltoLiquidPropaneGas
(LPG)PoweredMachines
CAUTION
Undernocircumstancesshouldyoullpropane
tanksbeyond80%capacity.
Ifyouuseanoverlledtank,itmayresult
inthereleaseofhighlyconcentratedand
extremely-ammableliquidpropane.Refertothe
Safetysectionofthe
Operator's Man ual .
1.RemovetheLPG-fueltankfromthefrontofthe.
2.Havethetanklledbytrainedandqualiedpersonnel.
