3.Cutthetiessecuringthetankbracketsandmovethem
outoftheway.
4.Alignthecenterholeoverthemountingpinthatpoints
straightupontheasshowninFigure8.
G013619
Figure8
1.Tankcollar
3.Centerhole
2.Mountingpin
Important:IfyoudonotinstalltheLPGtank
correctly,thevalvesandgaugesmaynotfunction
properly.
5.Latchthebracketsandensurethatthetankissecurely
fastenedtothemachine.
6.Carefullyconnectthefuelhose.Makesurethehoseis
notkinked.
7.Slowlyopenthefuelvalvetoequalizethepressurein
thetank.Ifyouopenthefuelvalvetooquickly,the
pressurereliefvalveisequippedwithabackpressure
checkvalvethatwillshutoffthefuelsupply.Ifthis
happens,closethefuelvalvecompletelyandwaitve
seconds.Slowlyopenthefuelvalve.
g030557
1
2
3
Figure9
1.LPGfuelhoseconnection
tting
3.Fuelgauge
2.Tankvalve
8.CheckforleaksasdescribedintheSafetysectionof
theOperator'sManual.
3
CheckingtheEngine-OilLevel
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoServicingthe
Engine-OilLevelintheOperator'sManual.
4
CheckingtheTirePressure
NoPartsRequired
Procedure
Pressure:13psi(90kPa)
Note:Checkthetirepressurebeforestartingthemachine.
RefertoyourOperator’sManualforthecorrecttiretype,
correctairpressureneeded,andprocedure.
5
CheckingtheWheelLugNut
Torque
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,checkthe
wheellugnuttorque;refertoCheckingtheWheelLugNuts
intheOperator'sManual
