6
CheckingtheGrassDeector
NoPartsRequired
Procedure
Ifthereareplastictiesholdingthegrassdeectorup,remove
themandlowerthedeectorintoplace.
WARNING
Anuncovereddischargeopeningcouldallowthe
machinetothrowobjectsintheoperator'sor
bystander'sdirectionandresultinseriousinjuryor
death.Also,contactwiththebladecouldoccur.
Neveroperatethelawnmowerunlessyouinstalla
coverplate,amulchplate,grassdeectororbagger.
1.Makesurethatoneendofthespringisinstalledbehind
thedeckedgebeforeinstallingtheboltasshownin
Figure10.
2.Placetheotherendofthespringaroundgrassdeector
(Figure10).
Important:Thegrassdeectormustbefreeto
rotatewithdownwardtension.Liftthedeectorup
tothefullopenpositionandensurethatitrotates
freely,withoutbindingintothefulldownposition.
1
2
3
2
4
G021 181
4
3
3
Figure10
1.GrassDeector3.Endofspring
2.Spring
4.Deckedge
7
InstallingaBattery(Diesel
MachinesOnly)
Partsneededforthisprocedure:
2J-bolt
2Wingnut
1Hold-downclamp
Procedure
Important:Thisprocedureonlyappliestomachines
thatdonotcomewithabatteryinstalled.
Purchasea12Vbatteryandinstallitintothemachine.The
enginerequiresaminimumof540CCA.
Usethehardwareincludedtoinstallthenewbattery.Referto
InstallingtheBatteryintheOperator'sManual.
8
InstallingaBattery(Gasoline
MachinesOnly)
Partsneededforthisprocedure:
1
Clamp
2
Wingnut(1/4inch)
2Batteryhold-down
Procedure
Important:Thisprocedureappliesonlytomachines
thatdonotcomewithabatteryinstalled.
1.Purchasea12Vbattery.
Modelswitha29hpengineandbelowrequireabattery
withaminimumof260CCA.
Modelswitha30hpengineandhigherrequireabattery
withaminimumof340CCA.
2.Locatethebattery-mountinghardwareandinstallit
intothemachine.RefertoInstallingtheBatteryinthe
Operator'sManual.
5
