9
ChargingtheBattery
NoPartsRequired
Procedure
WARNING
Chargingthebatteryproducesgassesthatcan
explodeandcauseseriousinjury.
•Keepcigarettes,sparksandamesawayfrom
thebattery.
•Makesuretheignitionswitchisoff.
•Ventilatewhenchargingorusingthebatteryin
anenclosedspace.
Important:Donotrunthemachinewiththebattery
disconnected;electricaldamagemayoccurtothe
engine.
Chargethebattery.RefertotheOperator'sManualfor
instructions.
Figure11
10
InstallingtheSeat
(InternationalMachines
UsingGasolineOnly)
Partsneededforthisprocedure:
1
Seat
1
Seatplate(xedseatsonly)
8
Flangenuts(3/8inch)—xedseatsonly
4
Spacers(3/8inch)—xedseatsonly
4
Flangenuts(3/8inch)—tiltingseatsonly
2
Longspacers(tilting,deluxeseatsonly)
4
Shortspacers(tilting,deluxeseatsonly)
InstallingtheSeatonModelswitha
FixedSeat
1.Removethehydraulic-unitshroudfromthemachine.
Figure12
1.Hydraulic-unitshroud2.Bolts
2.Removethe4nutsholdingtheseatplatetothe
machine.Discardthesenuts,theyareusedforshipping
only.
