Page #8 background imageLoading...
Page #8 background image
4.Plugtheharnessconnectorintotheseatswitchlocated
undertheseattowardsthefront.
Figure17
1.Seatswitch
3.Harnessconnector
2.Flangenuts
11
CheckingtheSeatBelt
(InternationalMachinesUsing
GasolineOnly)
NoPartsRequired
Procedure
Important:Ensurethebolttorqueissetbetween49
to61ft-lb(67to83N-m).
Checktheseatbeltangleandtheseatbeltbolttorquebefore
operating.
1.Checktheangleoftheseatbeltcomparedtothe
bottomoftheseat.Theangleneedstobe47degrees.
See(Figure18)
2.Ifneeded,settheseatbelttothecorrectangle.
3.Checkandsetthebolttorquebetween49to61ft-lb
(67to83N-m).
3
2
1
g014862
Figure18
1.Sideofseat
3.47degrees
2.Seatbeltbolt,Settorque
between49to61ft-lb(67
to83N-m)
12
InstallingtheMotion-Control
Levers(InternationalMachines
UsingGasolineOnly)
Partsneededforthisprocedure:
1Right-controllever
1
Left-controllever
4
Bolt(3/8x1inch)—2areassembled
4
Nut(3/8inch)—2areassembled
Procedure
1.Rotatethemotion-controlleverstotheupright
position.
2.Looselyinstallthecontrolleversontheinsideofthe
posts,using4boltsand4nuts.
Note:Installthecontrolleversinthetopandmiddle
holesforthehighpositionorthemiddleandbottom
holesforthelowposition,asdesired.
8
