Operating Manual BaseTravel 401/801
13. Technical data 14. Disposal instructions 15. Accessories
• Repairs may only be carried out by authorized Torqeedo Service Centers.
Owner‘s repair attempts immediately make the warranty claim void.
• In case of a warranty claim, please follow the warranty instructions at
the beginning of the instruction manual.
13. Technical data
* The effective power available for boat propulsion (measured after deducting all deficits including
propeller deficits. Definition of propulsion output = thrust power x speed)
BaseTravel
401 S
BaseTravel
401 L
BaseTravel
801 S
BaseTravel
801 L
Input power in watts 400 400 800 800
Rated power in volts 12 12 24 24
Propulsive power in watts* 172 172 370 370
Maximum overall efficiency in % 43% 43
% 46% 46%
Static thrust in lbf (kp) 35 (16) 35 (16) 62 (28) 62 (28)
Total weight in lbs (kg) 19.6 (8.9)
20.9 (9.5) 20.1 (9.1) 21.4 (9.7)
Maximum shaft length in inches (cm) 23 (59) 28 (71) 23
(59) 28 (71)
Integrated battery no no no no
Propeller dimensions in inches 12 x 10 12 x 10 12 x 10 12 x 10
Propeller speed in rpm max. 720 max. 720 max. 720 max. 720
Control Tiller-control Tiller-control Tiller-control Tiller-control
Steering 180° lockable 180° lockable 180° lockable 180° lockable
Tilting device manual manual manual manual
Trim device manual,
7-step
manual,
7-step
manual,
7-step
manual,
7-step
Stepless drive forwards/reverse yes yes yes yes
Additionally preset speeds yes yes yes yes
