Modelos M32
Owner´s Manual
II.- UNPACKING
III.- INSTALLATION
While unpacking the machine take special care in removing these components to be assembled
later. Make sure that all are accounted for*.
The grinding unit includes:
1 Headstock (10)
1 Worm (13)
1 Ring (17)
1 Blade or kinfe (15)
1 Plate (16)
*Note: for reference numbers see “Meat grinder diagram for components” (central pages).
The Meat grinder is ready to use. Before to install it, you only need to verify the next points:
1. Electrical installation meets the required specification of the equipment.
2. Place has an adequate illumination and leveled floor/work table (The meat grinder already
includes leveling support legs) .
3. Room is clean and meets the hygienic conditions for food processing.
IMPORTANT!:
Wash the unit before using for the first time, specially the grinding unit. Also use the includ-
ed food grade mineral oil to lubricate the plate (19) and knife (18) –See Cleaning section for
more details.
IMPORTANT!
The equipment must be correctly grounded to prevent possible damage by electrical
shock. The power cord must has a some kind of disconnection.
Also:
1 Pusher (1)
1 Product tray (2)
1 Bottle with mineral oil (24) -Approved by the
Food and Drug Administration-.
4 Support Legs (4)
RED (L1)
WHITE (L2)
BLACK (L3)
WHITE (L2)
RED (L1)
BLACK (L3)
