TOSHIBA/HOUSTON INVERTER PLANT
DESIGN DATA D-UM0029 Page 2 of 4
SUBJECT:
1000 Series UPS Options - Frequency Conversion
NO. REVISION DATE BY
FOR AUTHORIZED SERVICE PERSONAL ONLY
Install “FlashH08” Flash Program
There are two types of installation files for the Flash program. The one that is appropriate
for you can be determined by first checking the “CPU Version” that is displayed on the
LCD display in the front panel.
1.) If the format is XX.X
This means that the CPU is an R mask type. In this case you should run the
“Flash3062_R” program to install the “FlashH08” flash software. Further instructions on
configuration are explained below.
2) If the format is XX.XB
This means that the CPU is a B mask type. In this case you should run the “Flash3062_B”
program to install the “FlashH08” flash software. Further instructions on configuration are
explained below.
Use “FlashH08 ” to flash R mask type/B mask type CPU
1. To properly configure and utilize this software, terminate all applications that
occupy COM 1. (COM 1 is the default communication port for this software)
2. Connect the RS232 cable to the UPS from “COM1” of the PC.
3. Turn off the UPS, but keep the AC Line on. The proper procedure for this is
explained in the UPS manual that is included with the UPS.
4. Click on the appropriate “FlashH08” software that was installed in the previous
section.
i. If you installed the R mask type, it should be labeled “R Mask Flash” in the
title like the one shown below.
To Next Page
