Toshiba 13A25C Service Manual

GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 13 inch / 335.4mmV
System CRT Type Normal
Deflection
90 degree
Magnetic Field BV/BH +0.45G/0.18G
Color System NTSC
Speaker 1Speaker
Position Bottom
Size
3 Inch
Impedance 8 ohm
Sound Output MAX
1.0 W
10%(Typical)
0.8 W
NTSC3.58+4.43 /PAL60Hz No
G-2 Tuning Broadcasting System US System M
System Tuner and System 1Tuner
Receive CH Destination USA(W/ CATV)
Tuning System F-Synth
Input Impedance VHF/UHF 75 ohm
2 - 69, 4A, A-5 - A-1,
CH Coverage A - I, J - W, W+1 - W+84
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.50MHz
Preset CH No
Stereo/Dual TV Sound No
Tuner Sound Muting Yes
G-3 Power Power Source AC 120V AC 60Hz
DC
Power Consumption at AC
54 W at AC 120 V 60 Hz
Stand by (at AC)
5 W at AC 120 V 60 Hz
Per Year
-- kWh/Year
Protector Power Fuse Yes
G-4 Regulation Safety UL
Radiation FCC
X-Radiation DHHS
G-5 Temperature Operation +5oC ~ +40oC
Storage -20oC ~ +60oC
G-6 Operating Humidity Less than 80% RH
