4400 Series UPS Seismic Kit Installation Instructions – 94016-002
7
7
Anchor Bolt
5/16 in x 18
Press Nut
5/16 in x 18 Bolt
5/16 in Lock Washer
5/16 Washer
11
Fastener Group
FIGURE 2.7: 50 KVA SEISMIC FLOOR ANCHOR - DETAIL
FIGURE 2.8: SEISMIC DOOR
ANCHOR (50KVA)
