Toshiba e-STUDIO2010AC - Page 14

14
No.
Inspection item
Inspection result
Correspondence
12
SATA I/F &
SMART
NG [LINK DOWN]
NG [SPD]
Step 1. Check the installation status of the
HDD harness.
Step 2. Replace the HDD harness.
Step 3. Replace the HDD.
Step 4. Replace the SYS board.
NG [SMART]
Replace the HDD.
NG [ID]
Replace the HDD.
13
USB Host
OK?
Number of USB device connections
(NG will not be displayed)
14
USB Fax
OK?
Number of fax connections
(NG will not be displayed)
OK? [No fax
detected]
15
Scan Control
NG
Replace the SYS board.
16
LGC
Communication
NG
NG [LGC_EN]
NG [C900]
Step 1. Check the installation status of
CN132 on the SYS board and the
corresponding connector on the LGC
board.
Step 2 . Replace the harness connected
to CN132
Step 3. Replace the LGC board.
Step 4. Replace the SYS board.
NG [C963]
Step 1. Check the installation status of
CN131 and CN132 on the SYS board
and the corresponding connector on the
LGC board.
Step 2. Replace the harness connected
to CN131 and CN132 in sequence
Step 3. Replace the LGC board.
Step 4. Replace the SYS board.
NG [LGC_Reset]
Replace the SYS board.
17
SLG
Communication
*1. Here shows the
installed status of
the DF (No
ADF, RADF,
DSDF)
*2. Although it may
be displayed as
"WARMUP", it is
reference
information.
NG<DF*1>*2
Step 1. Update scanner firmware.
Step 2. Replace the SYS board.
NG <DF *1>
[SLG_EN] *2
Replace the SYS board.
NG <DF * 1>
[C260] * 2
Refer to C260 Troubleshoot of service
manual and check each item.
NG <DF * 1>
[C261] * 2
Refer to C261 Troubleshoot of service
manual and check each item.
NG <DF * 1>
[C262] * 2
Refer to C262 Troubleshoot of service
manual and check each item.
NG <DF * 1>
[C270] * 2
Refer to C270 Troubleshoot of service
manual and check each item.
(Continued on next page)
