e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 104
[EF16] Saddle Stitch Finisher stacker motor home position detection abnormality
[EF17] Saddle Stitch Finisher folding blade home position detection abnormality
[EF18] Saddle Stitch Finisher additional folding roller home position detection abnormality
Classification Error item
Finisher jam (Saddle section)
Check item Measures
Stacker carrier • Is there any mechanical problem when the stacker carrier
is moved?
Stacker home position sensor (S33) • Sensor check
• Connector check
• Harness check
Stacker motor (M14) • Motor check
• Connector check
• Harness check
Saddle controller board • Connector check (CN4)
• Board check
Replace parts Remarks
Stacker home position sensor (S33)
Stacker motor (M14)
Saddle controller board
Classification Error item
Finisher jam (Saddle section)
Check item Measures
Folding blade cam • Is there any mechanical problem when the folding blade
cam is rotated?
Folding blade home position sensor
(S35)
• Sensor check
• Connector check
• Harness check
Folding blade clutch (CLT3) • Clutch check
• Connector check
• Harness check
Saddle controller board • Connector check (CN15)
• Board check
Replace parts Remarks
Folding blade home position sensor
(S35)
Folding blade clutch (CLT3)
Saddle controller board
Classification Error item
Finisher jam (Saddle section)
To Next Page
