Toshiba E-studio5540c Service Manual

8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 105
[EF19] Saddle paper folding jam
[EF20] Saddle stacker jam
Check item Measures
Additional folding carrier • Is there any mechanical problem when the additional
folding carrier is moved?
Additional folding home position
sensor (S39)
• Sensor check
• Connector check
• Harness check
Additional folding motor (M20) • Motor check
• Connector check
• Harness check
Saddle controller board • Connector check (CN18, CN19)
• Board check
Replace parts Remarks
Additional folding home position
sensor (S39)
Additional folding motor (M20)
Saddle controller board
Classification Error item
Finisher jam (Saddle section)
Check item Measures
Finisher • Is there any paper remaining in the paper transport path in
the equipment or the saddle stitch section of the Finisher?
Exit transport sensor (S41) • Sensor check
• Connector check
• Harness check
Saddle controller board • Connector check (CN19)
• Board check
Replace parts Remarks
Exit transport sensor (S41)
Saddle controller board
Classification Error item
Finisher jam (Saddle section)
Check item Measures
Finisher • Is there any paper remaining in the paper transport path in
the equipment or the saddle stitch section of the Finisher?
Stacker paper detection sensor (S30) • Sensor check
• Connector check
• Harness check
Saddle controller board • Connector check (CN19)
• Board check
