Toshiba E-studio5540c Service Manual

8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 143
[CB51] Stapler shift home position error
[CB60] Stapler unit shift motor abnormality
Finisher control board • Connector check (CN2)
• Board check
Replace parts Remarks
Stapler
Finisher control board
Classification Error item
Finisher related service call The stapler is not at the home position. [MJ-1103/1104]
Check item Measures
Stapler • Is there any mechanical problem when the stapler is
moved?
• Connector check
• Harness check
Stapler unit home position sensor
(S10)
• Sensor check
• Connector check
• Harness check
Stapler unit shift motor (M4) • Motor check
• Connector check
• Harness check
Finisher control board • Connector check (CN1, CN5)
• Board check
Replace parts Remarks
Stapler
Stapler unit home position sensor
Stapler unit shift motor
Finisher control board
Classification Error item
Finisher related service call Stapler shift motor is not rotating or staple unit is not moving
normally. [MJ-1103/1104]
Check item Measures
Stapler • Is there any mechanical problem when the stapler is
moved?
• Connector check
• Harness check
Stapler unit shift motor (M4) • Motor check
• Connector check
• Harness check
Finisher control board • Connector check (CN1, CN5)
• Board check
Check item Measures
