8
© 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 17
C8C0 RADF
service call
RADF original reading start sensor
abnormality: The automatic adjustment for the
original reading start sensor has been
performed, but is ended unsuccessfully.
P. 8-131
C8E0 RADF communication protocol abnormality:
The system has to be stopped because the
control abnormality occurred.
P. 8-131
C900 Circuit related
service call
Connection error between SYS board and
LGC board
P. 8-132
C901 System format error for scanner P. 8-132
C940 Engine-CPU abnormality P. 8-133
C962 LGC board ID abnormality P. 8-133
C963 Connection detection error between the IMG
board and the LGC board
P. 8-133
C970 Process related
service call
High-voltage transformer abnormality:
Leakage of the main charger is detected.
P. 8-177
C9E0 Circuit related
service call
Connection error between SLG board and
SYS board
P. 8-134
CA00 Image control
related service call
Color registration abnormality P. 8-155
CA10 Laser optical unit
related service call
Polygonal motor abnormality: The polygonal
motor is not rotating normally.
P. 8-136
CA20 H-Sync detection error: H-Sync signal
detection PC board cannot detect laser
beams.
P. 8-137
CA47 SNS board abnormality: The SNS board does
not operate due to disconnection or the
harness breaking.
P. 8-138
CB00 Finisher related
service call
Finisher not connected: Communication error
has occurred between the equipment and
finisher. [MJ-1103/1104]
P. 8-139
CB01 Finisher communication error: Communication
error has occurred between the equipment
and finisher. [MJ-1103/1104]
P. 8-139
CB10 Entrance motor abnormality: The entrance
motor is not rotating normally. [MJ-1103/1104]
P. 8-139
CB11 Buffer tray guide motor abnormality: The
buffer tray guide motor is not rotating or the
buffer tray guide is not moving normally. [MJ-
1103/1104]
P. 8-139
CB12 Finisher related
service call
Buffer roller drive motor abnormality: The
buffer roller drive motor is not rotating or the
buffer roller is not moving normally. [MJ-1103/
1104]
P. 8-140
CB13 Finisher exit motor abnormality P. 8-140
CB14 Paper holding arm motor abnormality P. 8-141
CB30 Movable tray shift motor abnormality
[MJ-1103/1104]
P. 8-141
CB31 Movable tray paper-full detection error
[MJ-1103/1104]
P. 8-141
Error code Classification Contents Troubleshooting
