e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2014 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 18
CB40 Finisher related
service call
Rear aligning plate motor abnormality: Rear
aligning plate motor is not rotating or aligning
plate is not moving normally. [MJ-1103/1104]
Front alignment motor abnormality: The front
alignment motor is not rotating or the front
alignment plate is not moving normally. [MJ-
1103/1104]
P. 8-142
CB50 Stapler home position error: The stapler home
position sensor does not work. [MJ-1103/1104]
P. 8-142
CB51 Stapler shift home position error: The stapler is
not at the home position. [MJ-1103/1104]
P. 8-143
CB60 Stapler shift motor abnormality: Stapler shift
motor is not rotating or staple unit is not
moving normally. [MJ-1103/1104]
P. 8-143
CB80 Backup RAM data abnormality: Abnormality of
checksum value on finisher controller PC
board is detected when the power is turned
ON
P. 8-144
CB81 Flash ROM abnormality: Abnormality of
checksum value on finisher controller PC
board is detected when the power is turned
ON. [MJ-1103/1104]
P. 8-144
CB82 Finisher - Main CPU program error P. 8-144
CB83 Saddle Stitch Finisher - Main CPU program
error
P. 8-145
CB84 Hole Punch Unit - Main CPU program error P. 8-145
CB91 Saddle Stitch Finisher flash ROM abnormality P. 8-145
CB92 Saddle Stitch Finisher RAM abnormality P. 8-146
CB93 Additional folding motor abnormality P. 8-146
CB94 Saddle transport motor abnormality P. 8-146
CB95 Stacker motor abnormality P. 8-147
CBA0 Stitch motor (front) abnormality: Stitch motor
(front) is not rotating or rotary cam is not
moving normally. [MJ-1103/1104]
P. 8-147
CBB0 Stitch motor (rear) abnormality: Stitch motor
(rear) is not rotating or rotary cam is not
moving normally. [MJ-1103/1104]
P. 8-147
CBC0 Alignment motor abnormality: Alignment motor
is not rotating or aligning plate is not moving
normally. [MJ-1103/1104]
P. 8-148
CBE0 Paper folding motor abnormality: Paper
folding motor or paper folding roller is not
rotating normally. [MJ-1103/1104]
P. 8-148
CC20 Communication error between finisher and
saddle stitcher: Communication error between
finisher controller PC board and saddle
stitcher controller board [MJ-1103/1104]
P. 8-149
CC30 Stack transport motor abnormality: The stack
transport motor is not rotating or the stack
transport belt is not moving normally. [MJ-
1103/1104]
P. 8-149
Error code Classification Contents Troubleshooting
To Next Page
