1.GENERAL PRECAUTIONS
22 General Precautions
e-STUDIO206L/256/306/356/456, e-STUDIO256SE/306SE/356SE/456SE, e-STUDIO506/506SE, e-STUDIO306LP
y Both the Paper Feed Pedestal and the Large Capacity Feeder have 4 adjusters (antiskid devices)
underneath. After the equipment has been moved and installed, be sure to turn and lower them to fix it.
For the Paper Feed Pedestal, fix the fall-prevention stoppers after the adjusters have been adjusted.
Paper Feed Pedestal
Large Capacity Feeder
Before moving the equipment with the Desk installed, remove the front stabilizer. Be sure to reinstall it
after the equipment has been moved.
Do not install the equipment by yourself or try to move it once it has been installed. This could result in an
injury or damage to the device. Contact your service representative if the equipment needs to be installed or
moved.
Removing the stabilizer Installing the stabilizer
To Next Page
