Chapter 6 INFORMATION ABOUT EQUIPMENT
78
Finisher (MJ-1101)
Model name MJ-1101 (For DP-3590/DP-4590)
Type Floor type (Console type)
Acceptable paper size A3, A4, A4-R, A5-R, A6-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP, 8.5”SQ, 13”LG, 8K, 16K, 16K-R
Acceptable paper
weight
52 - 209 g/m
2
, 14 lb. Bond - 110 lb. Index
Number of sheets
stapled at a time
(Including 2 covers (64 -
209 g/m
2
, 17 lb. Bond -
110 lb. Index))
Paper size
64 - 80 g/m
2
17 - 20 lb. Bond
81 - 90 g/m
2
21 - 24 lb. Bond
91 - 105 g/m
2
25 - 28 lb. Bond
A4, B5, LT, 8.5”SQ, 16K 50 sheets 30 sheets 30 sheets
A3, A4-R, B4, FOLIO, LD, LG, LT-R, COMP,
13”LG, 8K
30 sheets 6 sheets 6 sheets
Stapling position Front, Rear, Double
Power source Supplied from the equipment
Dimensions 535 mm (21.4”) (W) x 598 mm (23.92”) (D) x 1092 mm (43.68”) (H)
Weight Approx. 34 kg (74.8 lb.)
Power consumption 70 W max.
Tray loading capacity of Finisher (MJ-1101)
Upper Tray
MJ-1101 with mixed paper not loaded
Mode Non-Sort
A4, A5-R, A6-R, B5, LT, ST-R, 8.5”SQ, 16K
36.75 mm, 1.45”
(250)
A3, A4-R, B4, B5-R, FOLIO, LD, LG, LT-R, COMP, 13”LG, 8K, 16K-R
18.4 mm, 0.72”
(125)
Lower Tray
MJ-1101 with mixed paper not loaded
Mode Non-Sort Sort/Group Staples loaded
A4, B5, LT,
8.5”SQ, 16K
250 mm, 9.84”
(2000)
250 mm, 9.84”
(2000)
Whichever of 250 mm (9.84”), 2000 sheets
or 30 sets is reached rst
A3, A4-R, B4, FOLIO, LD, LG, LT-R,
COMP, 13”LG, 8K
140 mm, 5.51”
(1000)
140 mm, 5.51”
(1000)
Whichever of 140 mm (5.51”), 1000 sheets
or 30 sets is reached rst
When mixed-size paper is loaded, the tray loading capacity should follow the specications for larger paper sizes in the above tables.
Unit: mm (with allowable error of ±7 mm or 0.276”)
Values in parentheses: Number of sheets (80 g/m
2
or 20 lb. Bond)
Unit: mm (with allowable error of ±7 mm or 0.276”)
Values in parentheses: Number of sheets (80 g/m
2
or 20 lb. Bond)
