Toshiba Qosmio F750 Series User Manual

Figure 2-6 The front of the computer with the display panel open
1112
10
7
8
1
6
5
7
13
4
2 3
9
14
Figure 2-7 The front of the computer with the display panel open
1. Wireless LAN antennas, Wireless
WAN/WiMAX antennas (not shown)*
8. Function buttons
2. Web Camera LED 9. Microphone
3. Web Camera 10. Touch Pad control buttons
4. Display screen 11. Touch Pad
5. Display hinge 12. Touch Pad ON/OFF button
6. Power button 13. Keyboard
7. Stereo speakers 14. LCD Sensor switch (not shown)
* Provided with some models.
Product appearance depends on the model you purchased.
Wireless LAN anten-
nas
Some computers in this series are equipped with
the Wireless LAN antennas.
Legal Footnote (Wireless LAN)
For more information regarding Wireless LAN, please refer to the Legal
Footnotes section in Appendix C.
Wireless WAN/WiMAX
antennas
Some computers in this series are equipped with
the Wireless WAN/WiMAX antennas.
Web Camera LED The Web Camera LED glows when the Web
Camera is operating.
Qosmio F750 Series
User's Manual 2-9
